ABB ACS355 - Page 291

Actual signals and parameters 291
AI2LO2 ORDLY State change when AI2 value < par. 8414 SEQ VAL 2 LOW
value or after delay time defined by parameter 8424 ST1
CHANGE DLY has elapsed.
35
SUPRV1
OVER
Logic value according to supervision parameters
3201…3203. See parameter group 32 SUPERVISION.
36
SUPRV2
OVER
Logic value according to supervision parameters
3204…3206. See parameter group 32 SUPERVISION.
37
SUPRV3
OVER
Logic value according to supervision parameters
3207…3209. See parameter group 32 SUPERVISION.
38
SUPRV1
UNDER
See selection SUPRV1 OVER.39
SUPRV2
UNDER
See selection SUPRV2 OVER.40
SUPRV3
UNDER
See selection SUPRV3 OVER.41
SPV1OVRORD
LY
State change according to supervision parameters
3201…3203 or when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed. See parameter group 32
SUPERVISION.
42
SPV2OVRORD
LY
State change according to supervision parameters
3204…3206 or when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed. See parameter group 32
SUPERVISION.
43
SPV3OVRORD
LY
State change according to supervision parameters
3207…3209 or when delay time defined by parameter 8424
ST1 CHANGE DLY has elapsed. See parameter group 32
SUPERVISION.
44
SPV1UNDORD
LY
See selection SPV1OVRORDLY.45
SPV2UNDORD
LY
See selection SPV2OVRORDLY.46
SPV3UNDORD
LY
See selection SPV3OVRORDLY.47
CNTR OVER State change when counter value exceeds the limit defined
by par. 1905 COUNTER LIMIT. See parameters
1904…1911.
48
CNTR UNDER State change when counter value is below the limit defined
by par. 1905 COUNTER LIMIT. See parameters
1904…1911.
49
LOGIC VAL State change according to logic operation defined by
parameters 8406…8410
50
ENTER
SETPNT
State change when drive output frequency/speed enters the
reference area (ie the difference is less than or equal to 4%
of the maximum reference).
51
All parameters
No. Name/Value Description Def/FbEq
