Parameters 245
28.22 Constant frequency
sel1
When bit 0 of parameter 28.21 Constant frequency function is
0 (Separate), selects a source that activates constant
frequency 1.
When bit 0 of parameter 28.21 Constant frequency function is
1 (Packed), this parameter and parameters 28.23 Constant
frequency sel2 and 28.24 Constant frequency sel3 select
three sources whose states activate constant frequencies as
follows:
DI3
Always off 0. 0
Always on 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273). 18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273). 19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273). 20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266). 24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266). 25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266). 26
Other [bit]
Source selection (see Terms and abbreviations on page 162). -
28.23 Constant frequency
sel2
When bit 0 of parameter 28.21 Constant frequency function is
0 (Separate), selects a source that activates constant
frequency 2.
When bit 0 of parameter 28.21 Constant frequency function is
1 (Packed), this parameter and parameters 28.22 Constant
frequency sel1 and 28.24 Constant frequency sel3 select
three sources that are used to activate constant frequencies.
See table at parameter 28.22 Constant frequency sel1.
For the selections, see parameter 28.22 Constant frequency
sel1.
DI4
No. Name/Value Description Def/FbEq16
Source defined
by par. 28.22
Source defined
by par. 28.23
Source defined
by par. 28.24
Constant frequency
active
000 None
1 0 0 Constant frequency 1
0 1 0 Constant frequency 2
1 1 0 Constant frequency 3
0 0 1 Constant frequency 4
1 0 1 Constant frequency 5
0 1 1 Constant frequency 6
1 1 1 Constant frequency 7
