Parameters 279
34.100 Timed function 1 Defines which timers are connected to combined timer 1.
0 = Not connected.
1 = Connected.
See 34.01 Timed functions status.
0b0000
0b0000…0b1111 Timers conn ected to comb ined timer 1. 1 = 1
34.101 Timed function 2 Defines which timers are connected to combined timer 2.
See 34.01 Timed functions status.
0b0000
34.102 Timed function 3 Defines which timers are connected to combined timer 3.
See 34.01 Timed functions status.
0b0000
34.110 Boost time function Defines which combined timers (that is, timers that are
connected to the combined timers) are activated with the
extra time function.
0b0000
0b0000…0b1111 Combined timers including the extra timer. 1 = 1
34.111 Boost time
activation source
Selects the source of extra time activation signal.
0 = Disabled.
1 = Enabled.
Off
Off 0. 0
On 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Timer 1 0 = Inactive. 1 = Active.
1 Timer 2 0 = Inactive. 1 = Active.
2 Timer 3 0 = Inactive. 1 = Active.
3 Timer 4 0 = Inactive. 1 = Active.
4 Timer 5 0 = Inactive. 1 = Active.
5 Timer 6 0 = Inactive. 1 = Active.
6 Timer 7 0 = Inactive. 1 = Active.
7 Timer 8 0 = Inactive. 1 = Active.
8 Timer 9 0 = Inactive. 1 = Active.
9 Timer 10 0 = Inactive. 1 = Active.
10 Timer 11 0 = Inactive. 1 = Active.
11 Timer 12 0 = Inactive. 1 = Active.
12…15 Reserved
Bit Name Description
0 Timed function 1 0 = Inactive. 1 = Active.
1 Timed function 2 0 = Inactive. 1 = Active.
2 Timed function 3 0 = Inactive. 1 = Active.
3…15 Reserved
