Parameters 287
35.23 Temperature 2
warning limit
Defines the warning limit for temperature supervision
function 2. When measured temperature 1 exceeds the limit,
warning A492 External temperature 2 is generated.
The unit is selected by parameter 96.16 Unit selection.
110 °C or
230 °F or
0...4000 ohm
-60…5000 °C or
-76…9032 °F or
0...5000 ohm
Warning limit for temperature monitoring function 2.
Note: If the measured temperature source selection (35.21)
is PTC analog I/O or PTC AI/DI Voltage divider tree, the
motor thermal protection function converts the analog input
signal (35.24) to PTC resistance value (ohms). Also this limit
is then a resistance value even the parameter name and unit
refer to motor temperature (°C or °F). You cannot change the
unit to ohm by the time being (96.16).
1 = 1 unit
35.24 Temperature 2 AI
source
Specifies the analog input when the setting of 35.11
Temperature 1 source requires measurement through an
analog input.
Not selected
Not selected None. 0
AI1 actual value Analog input AI1 on the control unit. 1
AI2 actual value Analog input AI2 on the control unit. 2
Other Source selection (see Terms and abbreviations on page 162). -
35.50 Motor ambient
temperature
Defines the ambient temperature of the motor for the motor
thermal protection model. The unit is selected by parameter
96.16 Unit selection.
The motor thermal protection model estimates the motor
temperature on the basis of parameters 35.50…35.55. The
motor temperature increases if it operates in the region above
the load curve, and decreases if it operates in the region
below the load curve.
WARNING! The model cannot protect the motor if the
motor does not cool properly because of dust, dirt, etc.
20 °C
-60…100 °C or
-76 … 212 °F
Ambient temperature. 1 = 1°
No. Name/Value Description Def/FbEq16
