Parameters 359
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
Timed function 1 Bit 0 of 34.01 Timed functions status (see page 273). 18
Timed function 2 Bit 1 of 34.01 Timed functions status (see page 273). 19
Timed function 3 Bit 2 of 34.01 Timed functions status (see page 273). 20
Supervision 1 Bit 0 of 32.01 Supervision status (see page 266). 24
Supervision 2 Bit 1 of 32.01 Supervision status (see page 266). 25
Supervision 3 Bit 2 of 32.01 Supervision status (see page 266). 26
Other [bit] Source selection (see Terms and abbreviations on page 162). -
96.13 User set I/O mode
in2
See parameter 96.12 User set I/O mode in1. Not selected
96.16 Unit selection Selects the unit of parameters indicating power, temperature
and torque.
0b0000
0b0000…0b1111 Unit selection wo rd. 1 = 1
96.20 Time sync primary
source
Defines the 1st priority external source for synchronization of
the drive’s time and date.
Panel link
Internal No external source selected. 0
Fieldbus A FENA/FPNO can get the time from SNTP server and set it as
time for the drive.
3
Embedded FB EFB BACnet MS/TP time-sync service can be used to set the
time for the drive.
6
Panel link You can set the time using control panel, or Drive composer
PC tool connected to the control panel.
8
Ethernet tool link You can set the time manually by using DCP over Ethernet.
The time can be set in the same way when you do it with USB
and panel.
9
96.51 Clear fault and
event logger
Clears all events from the drive’s fault and event logs. Done
Done 1 = No action 0
Reset 1 = Resets (clears) fault and event logger. 1
No. Name/Value Description Def/FbEq16
Bit Name Information
0 Power unit 0 = kW
1 = hp
1 Reserved
2 Temperature
unit
0 = °C
1 = °F
3 Reserved
4 Torque unit 0 = Nm (N·m)
1 = lbft (lb·ft)
5…15 Reserved
