358 Parameters
User3 IO active User set 3 has been selected by parameters 96.12 User set
I/O mode in1 and 96.13 User set I/O mode in2.
6
User4 IO active User set 4 has been selected by parameters 96.12 User set
I/O mode in1 and 96.13 User set I/O mode in2.
7
Reserved 8…19
User1 backup User set 1 has been saved or loaded. 20
User2 backup User set 2 has been saved or loaded. 21
User3 backup User set 3 has been saved or loaded. 22
User4 backup User set 4 has been saved or loaded. 23
96.11 User set save/load Enables the saving and restoring of up to four custom sets of
parameter settings.
The set that was in use before powering down the drive is in
use after the next power-up.
Notes:
• Some hardware configuration settings, such as I/O
extension module and fieldbus configuration parameters
(groups 14…16, 47, 50…58 and 92…93) are not included
in user parameter sets.
• Parameter changes made after loading a set are not
automatically stored – they must be saved using this
parameter.
• This parameter cannot be changed while the drive is
running
No action
No action Load or save operation complete; normal operation. 0
User set I/O mode Load user parameter set using parameters 96.12 User set I/O
mode in1 and 96.13 User set I/O mode in2.
1
Load set 1 Load user parameter set 1. 2
Load set 2 Load user parameter set 2. 3
Load set 3 Load user parameter set 3. 4
Load set 4 Load user parameter set 4. 5
Save to set 1 Save user parameter set 1. 18
Save to set 2 Save user parameter set 2. 19
Save to set 3 Save user parameter set 3. 20
Save to set 4 Save user parameter set 4. 21
96.12 User set I/O mode
in1
When parameter 96.11 User set save/load is set to User set
I/O mode, selects the user parameter set together with
parameter 96.13 User set I/O mode in2 as follows:
Not selected
Not selected 0. 0
Selected 1. 1
No. Name/Value Description Def/FbEq16
Status of source
defined by par.
96.12
Status of source
defined by par.
96.13
User parameter
set selected
00Set 1
10Set 2
01Set 3
11Set 4
