Parameters 217
33.35 Edge counter 1
warn message
Selects the optional warning message for signal edge counter
1.
Edge counter
1 exceeded
Edge counter 1
exceeded
A888 Edge counter 1. The message text can be edited on the
control panel by choosing Menu – Settings – Edit texts.
2
Counted main
contactor
A884 Main contactor.11
Counted output
relay
A881 Output relay.12
Counted motor
starts
A882 Motor starts.13
Counted power ups A883 Power ups.14
Counted DC
charges
A885 DC charge.15
33.40 Edge counter 2
actual
Displays the actual present value of signal edge counter 2.
The counter is incremented every time the signal selected by
parameter 33.43 Edge counter 2 source switches on or off (or
either, depending on the setting of 33.42 Edge counter 2
function). A divisor may be applied to the count (see 33.44
Edge counter 2 divider).
When the counter exceeds the limit set by 33.41 Edge counter
2 warn limit, bit 3 of 33.01 Counter status is set to 1. The
warning specified by 33.45 Edge counter 2 warn message is
also given if enabled by 33.42 Edge counter 2 function.
The counter can be reset from the Drive composer PC tool, or
from the control panel by keeping Reset depressed for over 3
seconds.
-
0…4294967295 Actual present value of signal edge counter 2. -
33.41 Edge counter 2
warn limit
Sets the warning limit for signal edge counter 2. 0
0…4294967295 Warning limit for signal edge counter 2. -
33.42 Edge counter 2
function
Configures signal edge counter 2. 0000b
0000b…1111b Edge counter 2 configuration word. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Function
0 Counter mode
0 = Loop: When the limit is reached, the counter is reset. The counter status (bit 3 of
33.01) remains 1 until the counter is again incremented. The warning (if enabled) stays
active for at least 10 seconds.
1 = Saturate: After the limit is reached, the counter status (bit 3 of 33.01) remains 1 until
33.40 is reset. The warning (if enabled) also stays active until 33.40 is reset.
1 Warning enable
0 = Disable: No warning is given when the limit is reached
1 = Enable: A warning (see 33.45) is given when the limit is reached
2 Count rising edges
0 = Disable: Rising edges are not counted
1 = Enable: Rising edges are counted
3 Count falling edges
0 = Disable: Falling edges are not counted
1 = Enable: Falling edges are counted
4…15 Reserved
