Parameters 265
60.10 M/F ref1 type Selects the type and scaling of reference 1 received from the
master/follower link. The resulting value is shown by 03.13
M/F or D2D ref1.
Auto
Auto Type and scaling are chosen automatically according to which
reference chain (see settings Torque, Speed, Frequency) the
incoming reference is connected to. If the reference is not
connected to any chain, no scaling is applied (as with setting
Transparent).
0
Transparent No scaling is applied. 1
General Generic reference with a scaling of 100 = 1 (ie. integer and
two decimals).
2
Torque The scaling is defined by parameter 46.03 Torque scaling.3
Speed The scaling is defined by parameter 46.01 Speed scaling.4
Frequency The scaling is defined by parameter 46.02 Frequency scaling.5
60.11 M/F ref2 type Selects the type and scaling of reference 2 received from the
master/follower link. The resulting value is shown by 03.14
M/F or D2D ref2.
For the selections, see parameter 60.10 M/F ref1 type.
Torque
60.12 M/F act1 type Selects the type/source and scaling of actual value ACT1
transmitted to the master/follower link.
Auto
Auto Type/source and scaling follow the type of reference 1
selected by parameter 60.10 M/F ref1 type. See the individual
settings below for the sources and scalings.
0
Transparent Reserved. 1
General Reserved. 2
Torque 01.10 Motor torque is sent as actual value 1. The scaling is
defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 1. The scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 1. The scaling
is defined by parameter 46.02 Frequency scaling.
5
60.13 M/F act2 type
Selects the type/source and scaling of actual value ACT2
transmitted to the master/follower link.
Auto
Auto Type/source and scaling follow the type of reference 2
selected by parameter 60.11 M/F ref2 type. See the individual
settings below for the sources and scalings.
0
Transparent Reserved. 1
General Reserved. 2
Torque 01.10 Motor torque is sent as actual value 2. The scaling is
defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 2. The scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 2. The scaling
is defined by parameter 46.02 Frequency scaling.
5
60.14 M/F follower
selection
(Effective in the master only.) Defines the followers from which
data is read. See also parameters 62.28…62.33.
None
Follower node 2 Data is read from the follower with node address 2. 2
None None. 0
No. Name/Value Description Def/FbEq16
