Parameters 271
Torque reference
act 5
26.75 Torque reference act 5 (page 185). 6731
Torque reference
used
26.02 Torque reference used (page 178). 6658
Follower CW B6
high
Otherwise identical to selection Follower CW, but bit 6 of the
follower control word is also kept on as long as the master is
modulating. This will allow the follower to stop along the stop
ramp of the master.
29
Other Source selection (see Terms and abbreviations on page 92). -
61.02 M/F data 2
selection
Preselects the data to be sent as word 2 onto the
master/follower link.
See also parameter 61.26 M/F data 2 value.
For the selections, see parameter 61.01 M/F data 1 selection.
Used speed
reference
61.03 M/F data 3
selection
Preselects the data to be sent as word 3 onto the
master/follower link.
See also parameter 61.27 M/F data 3 value.
For the selections, see parameter 61.01 M/F data 1 selection.
Torque
reference act
5
61.25 M/F data 1 value Displays the data to be sent onto the master/follower link as
word 1 as an integer.
If no data has been preselected by 61.01 M/F data 1
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 1 in master/follower communication.
61.26 M/F data 2 value Displays the data to be sent onto the master/follower link as
word 2 as an integer.
If no data has been preselected by 61.02 M/F data 2
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 2 in master/follower communication.
61.27 M/F data 3 value Displays the data to be sent onto the master/follower link as
word 3 as an integer.
If no data has been preselected by 61.03 M/F data 3
selection, the value to be sent can be written directly into this
parameter.
0
0…65535 Data to be sent as word 3 in master/follower communication.
61.45 Data set 2 data 1
selection
Parameters 61.45…61.50 preselect data to be sent in data
sets 2 and 4 to the external controller. These data sets are
used in ModuleBus communication with a “standard drive”
(60.50 DDCS controller drive type = ABB standard drive).
Parameters 61.95…61.100 display the data to be sent to the
external controller. If no data has been preselected, the value
to be sent can be written directly into these parameters.
For example, this parameter preselects the data for word 1 of
data set 2. Parameter 61.95 Data set 2 data 1 value displays
the selected data in integer format. If no data is preselected,
the value to be sent can be written directly into parameter
61.95.
None
None None. 0
CW 16bit Control Word (16 bits) 1
SW 16bit Status Word (16 bits) 4
Act1 16bit Actual value ACT1 (16 bits) 5
Act2 16bit Actual value ACT2 (16 bits) 6
No. Name/Value Description Def/FbEq16
