ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
IM/CM/S–EN Rev. R 61
…Control /…Loop 1 Output
Tracking
Configures the control output follow a tracking signal when in
Auto
control mode. In
Manual
control
mode, the output can be adjusted as normal. If the
Slew Rate
(see page
60
) function is enabled,
switching from
Manual
to
Auto
is bumpless. If the value set by the tracking signal differs to the manual
setting, the output ramps to its expected auto value at the speed set in the
Slew Rate
. If the
Signal
Source
is set to
None
,
tracking is disabled and the normal
PID
output is provided as the control output.
Source
Signal Source
Sets the source of the signal required to be tracked by the output in Auto control mode.
If set to None, output tracking is disabled.
Mode Selects the type of object tracking.
In Auto
Control output = tracking signal when in Auto control mode.
Auto + OP
Control output = tracking signal + change in PID output, when in Auto control mode.
When Enabled
When enable source is active, control output = tracking signal when in Auto control mode.
When Enabled +
OP
When enable source is active and the controller is in Auto control mode, the control output =
tracking signal + change in PID output.
Enable Source Sets the digital signal to enable output tracking.
Note. Applicable only if Mode is When Enabled or When Enabled + OP.
