ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
IM/CM/S–EN Rev. R 75
…Profile Parameters / …Common Settings / …Segment Options
Segment Options
G'teed Ramp/
Soak
Enables the Guaranteed Ramp/Soak (Holdback) function. When enabled (On), the relevant
configuration frames are displayed in Program / Segment menus to allow the Guaranteed Ramp/
Soak function to be configured.
Fast Run Mode This frame enables a mode that allows the profile program to be run 8 times faster than the
programmed times. In this mode guaranteed Ramp / Soak settings are ignored but wait
conditions are not overridden.
Enter Program
Name Enter the Program Name (up to 16 characters) to be used to identify the running program in the
Operator Page display.
Repeat Count Enter the number of times the program is to be repeated.
None The program will not be repeated (it will run once).
1 … 10 The program repeats as defined, for example, if '1' is selected the program runs twice.
Continuous The program runs continuously until stopped by the operator.
