ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
76 IM/CM/S–EN Rev. R
…Profile Parameters / …Enter Program
Setpoint Start/End
Start The start setpoint value for the first segment of the program.
Note. Available only if the SPT Start Condition parameter is set to Program Setpoint.
End Defines the end condition of the program:
Local Setpoint
The program will enter the Stop state and switch to the currently selected Local Setpoint.
Hold Setpoint
The program remains active and in control at the setpoint defined by the last segment. It remains
active until stopped, at which point the Control Setpoint switches to the current Local Setpoint.
Holdback
Hysteresis
Hysteresis values are used to hold the program when the process value deviates from the
setpoint by more than the hysteresis value as defined by the Guaranteed Ramp option for each
segment.
Note. Available only if Guaranteed Ramp is enabled.
Soak Set the hysteresis value applied to Soak segments.
Ramp Set the hysteresis value applied to Ramp segments.
