ControlMaster CM10, CM30 and CM50
Universal process controllers,
1
/8,
1
/4 and
1
/2 DIN 7 Advanced Level
78 IM/CM/S–EN Rev. R
…Profile Parameters / …Enter Program / …Enter Segments
Ramp Time
Increases or decreases the setpoint at a linear rate until the desired value is reached ( (if Ramp
Type = Time
). A Ramp Time segment requires the user to enter the desired end setpoint and the
desired ramp duration in hh:mm:ss.
Step
Changes the setpoint value from the end value to of the previous segment to a new value. A Step
segment requires the entry of the Step setpoint value.
End
Ends the program.
Period Select the soak or ramp period of the segment in hhh:mm:ss.
Note. Only displayed if Segment Type is configured as Soak or Ramp time.
Setpoint Select the required end setpoint value for the segment in engineering units.
Note. Only displayed if the Segment Type is configured as Ramp Rate or Ramp Time.
Ramp Rate Select the required Ramp Rate for the segment.
Note. Only displayed if Segment Type is Ramp Rate.
