Parameterization
104 FEX300, FEX500 OI/FEX300/FEX500-EN
Menu / Parameter Value range Description
Input/Output / Digital Output Mode
Function DO1 / DO2
Pulse F / Pulse R,
Pulse F / Logic,
Pulse FR / Logic,
Logic / Logic
Select the functions for the digital outputs DO1 and
DO2.
• Pulse F / Pulse R:
- DO1 = Pulse output forward direction
- DO2 = Pulse output reverse direction
• Pulse F / Logic:
- DO1 = Pulse output forward direction
- DO2 = Digital output
• Pulse FR / Logic:
- DO1 = Pulse output forward and reverse
direction.
- DO2 = Digital output
• Logic / Logic:
- DO1 = Digital output
- DO2 = Digital output
Default setting: Pulse FR / Logic.
Important (Notice)
The function of the digital output is defined in the
menu "Logic Setup".
DO1 Drive Passive, Active
The digital output DO1 can be configured as an
"active" or "passive" output. For information on the
current configuration, refer to the order confirmation.
Default setting: Passive
italics = Parameter can only be viewed at the "Advanced" password level.
1) Parameter / menu only available for FEP500 / FEH500.
