Parameterization
OI/FEX300/FEX500-EN FEX300, FEX500 113
Menu / Parameter Value range Description
Communication / PROFIBUS (continued) The menu is displayed only for devices with
PROFIBUS PA.
TOT1-Q Flowrate Display only
Current totalizer status in the selected unit from the
Transducer Block Flow, including status.
TOT2-Q Flowrate Display only
Current totalizer status in the selected unit from the
Transducer Block Flow, including status.
AI2-Internal Tot Fwd Display only
Current totalizer status of the forward totalizer in the
selected unit from the Transducer Block Flow,
including status.
AI3-Internal Tot Rev Display only
Current totalizer status of the reverse totalizer in the
selected unit from the Transducer Block Flow,
including status.
AI4-Diagnostics Display only
Current output value, including status. The channel
can be selected using the "AI4-Channel" parameter.
This function block delivers active values for FEX500,
only. For this purpose, the sensor mesurement or the
conductivity measurement must be switched on. For
FEX300 this function block delivers "0".
AI4-Channel Sensor Temp,
Conductivity
Select the channel output by AI4. The PV_SCALE and
OUT_SCALE structure is not adapted. This channel is
active for FEX500, only.
AO-Density Adjust Display only
Current density output value from the Transducer
Block Flow, including status.
DI-Alarm Info Display only
Current output value, including status. The channel
can be selected using the "DI-Channel" parameter.
DI-Channel
Maintenance, Out of Spec,
Function Check, Failure
Select the channel output by DI-Alarm Info
DO-Cyclic Control Display only
Current function, including status. The function can be
selected using the "DO-Channel" parameter.
DO-Channel
Off, Totalizer Reset(All),
Flowrate to Zero, System
Zero Adjust, Totalizer
Stop(All), Dual Range,
Start/Stop Batching
Select the function for DO-Cyclic Control.
italics = Parameter can only be viewed at the "Advanced" password level.
1) Parameter / menu only available for FEP500 / FEH500.
