Commissioning
OI/FEX300/FEX500-EN FEX300, FEX500 69
Instructions on using the Qmax menu (flow range end value)
The device is factory calibrated to the flow range end value Qmax
DN
, unless other customer
information is available. The ideal flow range end values are approximately 2-3 m/s (0.2 ... 0.3 x
Q
max
DN).
The smallest and largest possible flow range end values are shown in the table in chapter 6.6
"Flowmeter sizes, flow range".
Information regarding fa
ctory settings for further parameters (unless customer has
requested a specific parameterization)
Possible parameter settings Factory setting
Qmax Depending on the size (see
table)
QmaxDN (see table)
Sensor TAG Alphanumeric, max.
20 characters
None
Sensor Location TAG Alphanumeric, max.
20 characters
None
Q (Flowrate) Unit l/s; l/min; l/h; ml/s; ml/min;
m3/s; m3/min; m3/h; m3/d;
hl/h; g/s; g/min; g/h; kg/s;
kg/min; kg/h; kg/d; t/min; t/h;
t/d
l/min
Totalizer/Pulse Unit m3; l; ml; hl; g; kg; t l
Pulses per Unit 1
Pulse Width 0,1 ... 2,000 ms 100 ms
Damping ( 1 Tau) 0,02 ... 60 sec. 1
DO1 Alarm Config Pulse F/Pulse R, Pulse F,
General Alarm, Min. Flowrate
Alarm, Max. Flowrate Alarm,
Empty Pipe, TFE
Only available for
FEP500 / FEH500 are:
Gas Bubble, Conductivity,
Coating, Sensor Temp
Pulse F/Pulse R
DO1 Action Active, Passive Passive
DO2 Alarm Config F/R Signal, Pulse R, General
Alarm, Min. Flowrate Alarm,
Max. Flowrate Alarm, Empty
Pipe, TFE
Only available for
FEP500 / FEH500 are:
Gas Bubble, Conductivity,
Coating, Sensor Temp
F/R Signal
