Parameterization
OI/FEX300/FEX500-EN FEX300, FEX500 99
Menu / Parameter Value range Description
Device Setup / Transmitter / Units
Select the unit for the flowmeters. Totalizer/Pulse Unit
m3, l, ml, ft3, hl, g, kg, t, lb,
igal, ugal, bls, Ml, Mugal,
custom
Important (Notice)
When a mass flow unit is selected, the
corresponding density must be set in the "Device
Info / Transmitter / Density" menu.
Select the unit for the flow indicator. Q (Flowrate) Unit
l/s, l/min, l/h, ml/s, ml/min,
m3/s, m3/min, m3/h, m3/d,
Ml/d, ft3/s, ft3/min, ft3/h, ft3/d,
ugal/s, ugal/min, ugal/h,
ugal/d, Mugal/d, igal/s,
igal/min, igal/h, igal/d, bls/s,
bls/min, bls/h, bls/d, hl/h, g/s,
g/min, g/h, kg/s, kg/min, kg/h,
kg/d, t/min, t/h, t/d, lb/s,
lb/min, lb/h, lb/d, custom
Important (Notice)
When a mass flow unit is selected, the
corresponding density must be set in the "Device
Info / Transmitter / Density" menu.
Velocity Unit
m/s, m/min, cm/s, cm/min,
feet/s, feet/min, inch/s,
inch/min
Select the unit for the display of the flow velocity.
Select whether the user-defined flow unit is displayed
as a mass flow (with density) or volume flow (without
density).
Custom Vol. Type Volume Flow
Mass Flow
Important (Notice)
When a mass flow unit is selected, the
corresponding density must be set in the "Device
Info / Transmitter / Density" menu.
Custom Vol. Factor 0,0001 ... 100000 l/s
Enter the factor for a user-defined flow unit. The factor
relates to the flow per liter.
Custom Vol. String
Alphanumeric, max.
20 characters
Enter the name for the user-defined flow unit.
Select whether the used-defined totalizer unit is
displayed as a mass flow (with density) or volume flow
(without density).
Custom Tot. Type Volume Flow
Mass Flow
Important (Notice)
When a mass flow unit is selected, the
corresponding density must be set in the "Device
Setup / Transmitter / Density" menu.
Custom Tot. Factor 0,0001 ... 100000 l
Enter the factor for a user-defined totalizer unit. The
factor relates to the flow per liter.
Custom Tot. String
Alphanumeric, max.
20 characters
Enter the name for the user-defined totalizer unit.
italics = Parameter can only be viewed at the "Advanced" password level.
1) Parameter / menu only available for FEP500 / FEH500.
