ABB FSM4000 - Sensor SE41 F Permissible Pressure and Material

126 FSM4000 ELECTROMAGNETIC FLOWMETER | OI/FSM4000-EN REV. E
… 13 Specification
… Sensor SE41F
Min. permissible pressure as a function of measuring
medium temperature
Liner
Nominal diameter
DN
P
Operation
mbar abs
at
T
Operation
Hard rubber
15
to 1000
(1/2
to 40″)
0
< 90 °C (194 °F)
Soft rubber
50
to 1000
(2 to 40″)
0
< 60 °C (140 °F)
PTFE
10
to 600
(3/8
to 24″)
270
400
500
< 20 °C (68 °F)
< 100 °C (212 °F)
< 130°C (266 °F)
Thick PTFE
high
temperature
design
25
to 80 (1 to 3″)
100
to 250 (4 to 10″)
300 (12″)
0
67
27
< 180 °C (356 °F)
<
180 °C (356 °F)
< 180 °C (356 °F)
PFA
3
to 200
(1/10
to 8″)
0
0
< 130°C (266 °F)
< 180 °C (356 °F)
ETFE
25 to 1000 (1 to 40″)
100
< 130°C (266 °F)
Ceramic
carbide
25
to 1000
(1
to 40″)
0
< 80 °C (176 °F)
Sensor material
Parts
Standard
Others
Liner
PTFE, PFA, hard rubber, soft
rubber, ETFE
Ceramic carbide
Signal and ground
electrode for
•
Hard rubber
•
Soft rubber
Stainless steel 1.4571 (316 Ti)
Hastelloy B
-
3 (2.4600),
Hastelloy C
-
4 (2.4610),
titanium, tantalum,
platinum
-iridium,
stainless steel 1.4539
(904 L)
•
PTFE, PFA, ETFE
Hastelloy C
-4 (2.4610)
Stainless steel 1.4571
(316
Ti), Hastelloy B-3
(2.4600), titanium,
tantalum, platinum
-
iridium, stainless steel
1.4539 (904 L)
Grounding plate
Stainless steel 1.4571 (316 Ti)
On request
Protection plate
Stainless steel 1.4571 (316 Ti)
On request
Process connection material
Parts
Standard
Others
Flange
DN 3
to DN 15
(1/10 to 1/2″)
stainless steel*
stainless steel*
DN 20
to DN 300
(3/4
to 12″)
Steel galvanized**
DN 350
to DN 1000
(14 to 40″)
Steel painted**
Chassis
DN
3 to 300
(1/10
to 12″)
Pair case cast aluminum,
painted, paint coat, ≥
80
µm thick, RAL 9002
—
DN 350
to DN 1000
(14
to 40″)
Steel welded
construction,
painted, paint coat,
≥ 80 µm thick, RAL 9002
—
Terminal box
Aluminum alloy, painted,
≥ 80 µm thick, frame:
dark gray, RAL 7012
Cover: light gray, RAL 9002
—
Meter tube
Stainless steel 1.4301 (304)
—
Cable gland
Polyamide
—
The process connections are made of one of the materials listed below:
* 1.4301 (304), 1.4307, 1.4404 (316L) 1.4435 (316L), 1.4541 (321),
1.4571 (316Ti), ASTM A182 F304, ASTM A182 F304L, ASTM A182 F316L,
ASTM A182 F321, ASTM A182 F316TI, ASTM A182 F316, 0Cr18Ni9,
0Cr18Ni10, 0Cr17Ni13Mo2, 0Cr27Ni12Mo3, 1Cr18Ni9Ti, 0Cr18Ni12Mo2Ti
** 1.0038, 1.0460, 1.0570, 1.0432, ASTM A105, Q255A, 20#, 16Mn
