FSM4000 ELECTROMAGNETIC FLOWMETER | OI/FSM4000-EN REV. E 21
Torque information
Flange and wafer type devices, model SE41F / SE21F / SE21W
Nominal diameter DN
Nominal pressure
Max. tightening torque [Nm]
mm
In
PN
Hard/soft rubber lining
PTFE, PFA, ETFE lining
Steel flange
Stainless steel flange
Steel flange
Stainless steel flange
3
to 10
1)
¹⁄₁₀
to ⅜”
1)
PN40
-
-
12.43
12.43
PN63/100 - - 12.43 12.43
CL150
-
-
12.98
12.98
CL300 - - 4.94 17.38
JIS 10K
-
-
12.43
12.43
15
½”
PN40 6.74 4.29 14.68 14.68
PN63/100
13.19
11.2
22.75
22.75
CL150 3.65 3.65 12.98 12.98
CL300
4.94
3.86
4.94
17.38
CL600 9.73 9.73 - -
JIS 10K
2.84
1.37
14.68
14.68
20
¾”
PN40 9.78 7.27 20.75 20.75
PN63/100
24.57
20.42
42.15
42.15
CL150 5.29 5.29 18.49 18.49
CL300
9.77
9.77
33.28
33.28
CL600 15.99 15.99 - -
JIS 10K
4.1
1.88
20.75
20.75
25
1”
PN40 13.32 8.6 13.32 8.6
PN63/100
32.09
31.42
53.85
53.85
CL150 5.04 2.84 23.98 23.98
CL300
17.31
16.42
65.98
38.91
CL600 22.11 22.11 - -
JIS 10K
8.46
5.56
26.94
26.94
32
1¼”
PN40 27.5 15.01 45.08 45.08
PN63/100
42.85
41.45
74.19
70.07
CL150 4.59 1.98 29.44 29.44
CL300
25.61
14.22
45.52
45.52
CL600 34.09 34.09 - -
JIS 10K
9.62
4.9
45.08
45.08
40
1½”
PN40 30.44 23.71 56.06 56.06
PN63/100
62.04
51.45
97.08
97.08
CL150 5.82 2.88 36.12 36.12
CL300
33.3
18.41
73.99
73.99
CL600 23.08 23.08 - -
JIS 10K
12.49
6.85
56.06
56.06
1) Connection flange DIN/EN1092-1 = DN10 (3/8”), connection flange ASME = DN15 (1/2”)
