FSM4000 ELECTROMAGNETIC FLOWMETER | OI/FSM4000-EN REV. E 127
Storage temperature
−20 to 70 °C (−4 to 158 °F)
IP rating in accordance with EN 60529
IP 65/IP 67
IP 68 (option)
Pipe vibration according to EN 60068-2-6
Transmitter
• In the range of 10 to 55 Hz, max. deflection 0.15 mm
Sensor
• In the range of 10 to 55 Hz, max. deflection 0.15 mm
• In the range of 10 to 55 Hz, max. acceleration 2 g
Designs
The flange devices are compliant with the installation lengths
determined according to ISO 13359.
Material loads for process connections
Limits for allowable fluid temperature (TS) and allowable
pressure (PS) are a function of the liner and flange material used
(see the factory tag and name plate of the unit).
Temperature limits
10 °C
15 °C
rubber
10 °C
15 °C
10 °C
25 °C
10 °C
25 °C
10 °C
20 °C
Figure 73: Stainless steel DIN flange up to DN 600 (24”)
