ABB FSM4000 - Sensor SE41 F Pressure-Temperature Graphs

128 FSM4000 ELECTROMAGNETIC FLOWMETER | OI/FSM4000-EN REV. E
… 13 Specification
… Sensor SE41F
Figure 74: Stainless steel ASME flange up to DN 400 (16”) (CL150/300) to DN 1000 (40”)
(CL150) to DN 200 (8”) (CL 600)
Figure 75: Steel DIN flange up to DN 600 (24”)
Figure 76: Steel ASME flange up to DN 400 (16”) (CL150/300) to DN 1000 (40”) (CL150)
JIS 10K-B2210 flange
Nominal
diameter
DN
Material
PN
TS
PS [bar]
32
to 400
(1¼ to 16”)
Stainless steel
10
−
25 to +180 °C
(−13 to +356 °F)
10
32 to 400
(1¼ to 16”)
Steel
10
−
10 to +180 °C
(14 to 266 °F)
10
A
DN 1000 PN 10
B
DN 900 PN10, DN 800 PN 10, DN
700 PN 10
C
DN 1000 PN 16
D
DN 900 PN 16, DN 800 PN 16
E
DN 700 PN 16
Figure 77: Stainless steel DIN flange, DN 700 to DN 1000 (28 to 40”)
A
DN 1000 PN 10
B
DN 900 PN10, DN 800 PN 10, DN
700 PN 10
C
DN 1000 PN 16
D
DN 900 PN 16, DN 800 PN 16
E
DN 700 PN 16
Figure 78: Steel DIN flange, DN 700 to DN 1000 (28 to 40”)
