FSM4000 ELECTROMAGNETIC FLOWMETER | OI/FSM4000-EN REV. E 65
Submenu / parameter Value range Remark
Span Cs
View only
Flowmeter sensor span value Cs.
100.0 %
Zero Cz
View only
Flowmeter sensor zero value Cz. For old sensor always 0 %.
0.0 %
Phase View only Phase relationship between reference and signal voltages. For
SE41F and SE21 transmitters always 90°.
90
Reference voltage
View only
Display the reference voltage, for ‘Older Model’ selection. Not
displayed for model 10D1422.
70 mV
Meter factor View only Displayed only if flowmeter sensor 10D1462/72 is selected
1.0
Order no.
View only
Display the ABB order number for the flowmeter sensor.
‘-----------------------’
Submenu
Option available only
with ‘Older sensor’
Menu required for older sensors only.
Visible only if 50 or 60 Hz has been selected in the
‘Service/Primary Adjust/Frequency Primary’ menu.
By selecting ‘Yes’, the primary setting is started and the user is
guided in a similar manner as for the ‘Easy Set-Up’ direction.
Primary Setup
Line frequency 50, 60 Hz Displays the mains frequency for the flowmeter sensor. Option
available only with ‘Older sensor’.
50 Hz
Sensor model
Selection of the older
sensor
Display the connected flowmeter sensor model:
DS4_
Nominal diameter Select the size of the
connected flowmeter
sensor
Select the size of the flowmeter sensor. Option available only
with ‘Older sensor’.
100 mm 4 in
Reference voltage
Enter the reference
voltage
Display the reference voltage, only for ‘Older sensor’ option, see
name plate for sensor. Not displayed for models 10D1422,
10D1462/72.
70 mV
Meter factor Numerical entry Display the meter factor, only for older model 10D1462/72; see
name plate for flowmeter sensor. See also page 109.
1.0
