PROFIsafe 207
Note: The states of all FSO inputs and outputs are shown in the PROFIsafe
message. These states also show the states of SBC outputs and feedback inputs.
ABB_PS2 profile F-Output user data
This table shows the bit order of the F-Output data, which is included in the
PROFIsafe message sent to the FSO module from the safety PLC. For all the bits in
the F-Output data, one (1) means active and zero (0) non-active.
Intege
r16
6 Safe_speed_MSB The current motor speed value from FSO (MSB).
Intege
r16
7 Safe_speed_LSB The current motor speed value from FSO (LSB).
*)
The safety PLC must ignore the value of the reserved bits. This ensures the compatibility
with future versions of the PROFIsafe profile where the reserved bits may be used.
Type Octet Bit Name Description
Unsig
ned16
(used
as
bits)
0 0 SLS2_request SLS2 (Safely-limited speed) activation requested by
the controller.
1 SLS1_request SLS1 (Safely-limited speed) activation requested by
the controller.
2Reserved
*)
Must not be used (must be 0).
3Reserved
*)
Must not be used (must be 0).
4 SS1_request SS1 (Safe stop 1) activation requested by the
controller.
5 SSE_request SSE (Safe stop emergency) activation requested by
the controller.
6 POUS_request POUS (Prevention of unexpected start-up)
activation request by the controller.
7 STO_request STO (Safe torque off) activation requested by the
controller.
Unsig
ned16
(used
as
bits)
1 0 SDI_N_ activate SDI_N (Safe direction) activation requested by the
controller.
1 SDI_P_ activate SDI_P (Safe direction) activation requested by the
controller.
2Reserved
*)
Must not be used (must be 0).
3Reserved
*)
Must not be used (must be 0).
4Reserved
*)
Must not be used (must be 0).
5Reserved
*)
Must not be used (must be 0).
6 SLS4_request SLS4 (Safely-limited speed) activation requested by
the controller.
7 SLS3_request SLS3 (Safely-limited speed) activation requested by
the controller.
Type Octet Bit Name Description
