ABB FSO-21 - Configuration; Configuring the FB Module

PROFIsafe 229
Configuration
 Configuring the FB module
You can use either the drive control panel or the Drive composer pro PC tool to
modify the settings of the FB module.
Note: This section describes only the most important configuration steps. For more
detailed information, see FPNO-21 PROFINET fieldbus adapter module user’s
manual (3AXD50000158614 [English]), FENA-01/-11/-21 Ethernet adapter module
user’s manual (3AUA0000093568 [English]) and the drive firmware manual.
Note: Example values in the table below are chosen based on the upcoming example
project.
Parameters for the PROFINET communication
1. Depending on the drive, you can configure the FB module as fieldbus channel A
or B. Enable the communication between the drive and the FB module for the
option slot where the FB module is installed in (parameter 50.01 FBA A enable or
50.31 FBA B enable).
2. Set the FB module parameters that correspond to the selected fieldbus channel.
Parameter groups 51, 52 and 53 include the settings for FBA A and groups 54, 55
and 56 for FBA B.
Groups 52, 53, 55 and 56 configure the contents of the normal PROFINET cyclic
communication by mapping the words in the PROFINET frame to the desired
drive parameters.
Groups 51 and 54 configure the PROFINET connection.
Index Name/Value Description Example
value
50.01 FBA A enable Enables/disables communication between the
drive and fieldbus adapter A and specifies the slot
the adapter is installed into.
1
Option slot 1 Communication between drive and fieldbus
adapter A enabled. The adapter is in slot 1.
50.31 FBA B enable Enables/disables communication between the
drive and fieldbus adapter B, and specifies the
slot the adapter is installed into.
0
Disable Communication between drive and fieldbus
adapter B disabled.
51/54.01 FBA A/B type Shows the type of the connected fieldbus adapter
module A/B.
This parameter is read-only.
Ethernet
