Technical data 519
For the environmental limits for the drive, refer to the hardware manual of your drive.
Safety functions
Relative humidity 5…95%, no condensation allowed. If corrosive gases are present,
the maximum allowed humidity is 60%.
Contamination levels
IEC 60721-3-x
No contaminants, conductive dust or corrosive dust allowed.
Use at least IP54 enclosure in an environment where conductive
dust or corrosive dust exists.
Chemical gases Class 3C2 Class 1C2 Class 2C2
Solid particles Class 3S2. No
conductive dust
allowed.
Class 1S3 Class 2S2
Vibration
IEC 60068-2-6,
Test Fc (2007-12)
Frequency range:
2…9 Hz: Constant deflection = 7 mm
9…200 Hz: Constant acceleration = 20 m/s
2
Shock IEC 60068-2-27
Test Ea (2008-02)
Peak acceleration 50 m/s
2
. Pulse duration 30 ms, 3 pulses in each
direction with STO and SS1 functions activated.
Atmospheric pressure 70 … 106 kPa (0.7 … 1.05 atmospheres)
Stopping functions
STO Safe torque off
SBC Safe brake control
SS1 Safe stop 1
SSE Safe stop emergency
Speed-related functions
SLS Safely-limited speed
Variable SLS Variable Safely-limited speed
SMS Safe maximum speed
SSM Safe speed monitor
SDI Safe direction
SAR Safe acceleration range - SAR is used only for deceleration with SS1, SSE,
SDI and SLS and Variable SLS functions.
Other
POUS Prevention of unexpected start-up
Operation
installed for
stationary use
Storage
in the protective
package
Transportation
in the protective
package
