Parameters 449
Status and control words
This table lists the FSO module and drive status and control words. You can view
these in the ACS880/DCS880 parameter tab of Drive composer pro.
WARNING! This data is purely informative. Do not use it for any functional
safety purposes.
Index Name/Value Description
Safety
200.01 FSO speed ch1 Shows the motor speed estimate 1 of the FSO module. The
FSO module reads the value from the drive via communication
channel 1.
When safety encoder is used with FSE-31 module, this
parameter shows the speed measured with the safety
encoder.
0.00 … rpm Speed
FbEq16: 1 = 1 rpm; FbEq32: 100 = 1 rpm
200.02 FSO speed ch2 Shows the motor speed estimate 2 of the FSO module. The
FSO module reads the source data from the drive via
communication channel 2 and calculates the speed estimate 2
using the data.
When safety encoder is used with FSE-31 module, this
parameter shows the speed measured with the safety
encoder.
Note: For a DCS880 drive, the value of this parameter is
always 0 when no encoder is used.
0.00 … rpm Speed
FbEq16: 1 = 1 rpm; FbEq32: 100 = 1 rpm
200.03 FSO DI status Shows the states of the FSO digital inputs.
Bit Name Values
0 Input X113:1 0 = Off, 1 = On
1 Input X113:2 0 = Off, 1 = On
2 Input X113:3 0 = Off, 1 = On
3 Input X113:4 0 = Off, 1 = On
4 Input X114:1 0 = Off, 1 = On
5 Input X114:2 0 = Off, 1 = On
6 Input X114:3 0 = Off, 1 = On
7 Input X114:4 0 = Off, 1 = On
8-15 Reserved
