Verification and validation 475
Validation of the SLS functions
Note: STO and SSE validation test must always be done before SLS or any other
validation tests.
Follow these steps to validate all SLS functions (SLS1...4) that are used in the
application. SLS1 is used as an example later in this section.
Note: If SLS4 limits are changed, this will have an impact on varSLS function also,
which means that both of these functions must be validated.
1. Make sure that the input for the SLS1 function is wired and configured according
to the wiring diagram.
2. Make sure that the SLS1 function is configured according to your design. For a
configuration example, see section Configuring SLS on page 362. Check these
settings:
Activation:
• 200.21 SLS1 activity and version
• SLSx.11 SLS1 input A
• SLSx.12 SLS1 input B (only for SLS1).
Functionality for the SLS function:
• 200.22 SLS1 limit negative
• 200.23 SLS1 limit positive
• SLSx.13 SLS1 trip limit negative
• SLSx.14 SLS1 trip limit positive.
Acknowledgement:
• SLSx.02 SLS acknowledgement
• FSOGEN.42 Acknowledgement button input if manual acknowledgement is
used.
Functionality:
a) with ramp monitoring:
• SLSx.03 SLS activation monitoring method = Ramp
• 200.202 SAR speed scaling
• 200.112 SAR1 ramp time to zero
• SARx.02 SAR initial allowed range
• SARx.21 SAR1 min ramp time to zero
• SARx.22 SAR1 max ramp time to zero
• drive parameter 23.23 emergency stop time, If 200.112 SAR1 ramp time to
zero = 0 ms.
OR
b) with time monitoring:
