430 Parameters
SLSx.57 Mute time for
variable SLS
Sets the variable SLS specific mute time for
limit hit situations.
This parameter is effective only with the safe
speed estimate.
0 ms
0…10000 ms
41
SMS
Parameters for the SMS function
SMS.13 SMS trip limit
negative
Sets the negative speed limit that trips the
drive for the SMS function.
0.0 rpm
-35880.0 …0.0 rpm Speed
SMS.14 SMS trip limit
positive
Sets the positive speed limit that trips the
drive for the SMS function.
0.0 rpm
0.0 …35880.0 rpm Speed
SMS.17 Mute time for SMS Sets the SMS specific mute time for limit hit
situations.
This parameter is effective only with the safe
speed estimate.
0 ms
0…5000 ms
41
SARx
Parameters for SARx ramps
SARx.02 SAR initial allowed
range
Sets the initial allowed range for the SARx
ramp. This parameter moves the location of
the maximum monitoring ramp forward on
the time axis, when monitoring is started.
The slope of the ramp stays the same as
defined with parameters 200.202 and
SARx.12 (SAR0) or SARx.22 (SAR1).
For more information, see section Ramp
monitoring on page 57.
0ms
0…60,000 ms Time
SARx.11 SAR0 min ramp
time to zero
Sets the minimum ramp time for the SAR0
ramp monitoring.
0ms
0…1,799,999 ms Time.
Note: With value 0 ms, the ramp is not
monitored
SARx.12 SAR0 max ramp
time to zero
Sets the maximum ramp time for the SAR0
ramp monitoring.
1ms
1…3,600,000 ms Time
SARx.21 SAR1 min ramp time
to zero
Sets the minimum ramp time for the SAR1
ramp monitoring.
0ms
0…1,799,999 ms Time
Note: With value 0 ms, the ramp is not
monitored
Index Name/Value Description Factory
default
