422 Parameters
None No output connected
DO X113:7 & X114:7 Redundant output X113:7 & X114:7
DO X113:8 & X114:8 Redundant output X113:8 & X114:8
DO X113:9 & X114:9 Redundant output X113:9 & X114:9
DO X113:7 Single output X113:7
DO X113:8 Single output X113:8
DO X113:9 Single output X113:9
DO X114:7 Single output X114:7
DO X114:8 Single output X114:8
DO X114:9 Single output X114:9
SS1.22 SS1 completed
output
Sets the digital output that indicates the
completion of the SS1 function. See the
diagrams in section Safe stop 1 (SS1) on
page 79.
None
None No output connected
DO X113:7 & X114:7 Redundant output X113:7 & X114:7
DO X113:8 & X114:8 Redundant output X113:8 & X114:8
DO X113:9 & X114:9 Redundant output X113:9 & X114:9
DO X113:7 Single output X113:7
DO X113:8 Single output X113:8
DO X113:9 Single output X113:9
DO X114:7 Single output X114:7
DO X114:8 Single output X114:8
DO X114:9 Single output X114:9
41
SLSx
Parameters for the SLS1…4 functions
SLSx.02 SLS
acknowledgement
Sets the acknowledgement method used in
the SLS1
…4 functions.
Manual
Manual The FSO module reads the external SLS
acknowledgement signal through the digital
input defined by parameter FSOGEN.42
Acknowledgement button input. The FSO
module accepts the acknowledgement after
the SLS request has been removed and the
SLS limit has been achieved (that is, SLS
monitoring is on).
Automatic The FSO module generates the SLS
acknowledgement signal automatically after
the SLS request has been removed and the
SLS limit has been achieved (that is, SLS
monitoring is on).
Index Name/Value Description Factory
default
