Parameters 425
SLSx.12 SLS1 input B Sets the secondary digital input for the SLS1
function. The secondary input is mostly used
for cascade connection (only SLS1 can be
cascaded).
See parameters SAFEIO.12 Cascade A and
SAFEIO.13 Cascade B.
None
None No input connected
DI X113:1 & X114:1 Redundant input X113:1 & X114:1
DI X113:2 & X114:2 Redundant input X113:2 & X114:2
DI X113:3 & X114:3 Redundant input X113:3 & X114:3
DI X113:4 & X114:4 Redundant input X113:4 & X114:4
DI X113:1 Single input X113:1
DI X113:2 Single input X113:2
DI X113:3 Single input X113:3
DI X113:4 Single input X113:4
DI X114:1 Single input X114:1
DI X114:2 Single input X114:2
DI X114:3 Single input X114:3
DI X114:4 Single input X114:4
SLSx.13 SLS1 trip limit
negative
Sets the SLS1 negative speed limit that trips
the drive.
0.0 rpm
-35880.0 …0.0 rpm Speed
SLSx.14 SLS1 trip limit
positive
Sets the SLS1 positive speed limit that trips
the drive.
0.0 rpm
0.0…35880.0 rpm Speed
SLSx.15 SLS1 output A Sets the primary digital output for the SLS1
function. Active when SLS1 function is active
and the motor speed is below the SLS1 limit
(that is, when the SLS1 monitoring is on).
None
None No output connected
DO X113:7 & X114:7 Redundant output X113:7 & X114:7
DO X113:8 & X114:8 Redundant output X113:8 & X114:8
DO X113:9 & X114:9 Redundant output X113:9 & X114:9
DO X113:7 Single output X113:7
DO X113:8 Single output X113:8
DO X113:9 Single output X113:9
DO X114:7 Single output X114:7
DO X114:8 Single output X114:8
DO X114:9 Single output X114:9
Index Name/Value Description Factory
default
