442 Parameters
SAFEIO.12 Cascade A Sets the cascade connection A for the FSO
module. For each FSO module in cascade
A, the digital input connected to the safety
function is also internally connected to the
corresponding digital output of the FSO
module (digital input -> digital output). This
resembles a master/follower connection.
See section Cascade on page 62.
None
None Not cascaded
X113:1 & X114:1 ->
X113:7 & X114:7
Redundant cascade X113:1 & X114:1 ->
X113:7 & X114:7
X113:2 & X114:2 ->
X113:8 & X114:8
Redundant cascade X113:2 & X114:2 ->
X113:8 & X114:8
X113:3 & X114:3 ->
X113:9 & X114:9
Redundant cascade X113:3 & X114:3 ->
X113:9 & X114:9
X113:1 -> X113:7 Single cascade X113:1 -> X113:7
X113:2 -> X113:8 Single cascade X113:2 -> X113:8
X113:3 -> X113:9 Single cascade X113:3 -> X113:9
X114:1 -> X114:7 Single cascade X114:1 -> X114:7
X114:2 -> X114:8 Single cascade X114:2 -> X114:8
X114:3 -> X114:9 Single cascade X114:3 -> X114:9
SAFEIO.13 Cascade B Sets the cascade connection B for the FSO
module. For each FSO module in cascade
B, the digital input connected to the safety
function is also internally connected to the
corresponding digital output of the FSO
module (digital input -> digital output).
See section Cascade on page 62.
None
None Not cascaded
X113:1 & X114:1 ->
X113:7 & X114:7
Redundant cascade X113:1 & X114:1 ->
X113:7 & X114:7
X113:2 & X114:2 ->
X113:8 & X114:8
Redundant cascade X113:2 & X114:2 ->
X113:8 & X114:8
X113:3 & X114:3 ->
X113:9 & X114:9
Redundant cascade X113:3 & X114:3 ->
X113:9 & X114:9
X113:1 -> X113:7 Single cascade X113:1 -> X113:7
X113:2 -> X113:8 Single cascade X113:2 -> X113:8
X113:3 -> X113:9 Single cascade X113:3 -> X113:9
X114:1 -> X114:7 Single cascade X114:1 -> X114:7
X114:2 -> X114:8 Single cascade X114:2 -> X114:8
X114:3 -> X114:9 Single cascade X114:3 -> X114:9
Index Name/Value Description Factory
default
