Encoderless SLS or SS1-r
Safely-limited speed (SLS) without encoder includes the following subsystems: FSO
encoderless speed measurement, FSO Digital input, FSO Logic (1 or 2), FSO STO
output, FSO digital output (optional), and Drive STO. Block diagram is equal to SS1-r
function.
SLS with encoder, SDI and SS1-r
Safely-limited speed (SLS) with encoder includes the following subsystems: safety
encoder (not provided by ABB), FSE-31, FSO Digital input, FSO Logic (1 or 2), FSO
STO output, FSO Digital output (optional), and Drive STO. Block diagram is equal to
SDI and SS1-r.
1 FSO encoderless speed measurement
2 FSO Digital input
3 FSO Logic (1 or 2)
4 FSO STO output
5 FSO Digital output (optional)
6Drive STO
1 Safety encoder, input device
2 FSE-31
3 FSO Digital input
4 FSO Logic (1 or 2)
5 FSO STO output
6 FSO Digital output (optional)
7Drive STO
1 2 3 4 5 6
1 2 3 4 5 6 7
