ABB IRB 120 - Page 246

InformationAction
See figure 3 in:
• Location of calibration pins on
page 242
Rotate axis 3 manually until the two calibration
pins are in contact with each other.
4
Choose fine calibration from Calib menu.5
Choose Calibrate on the the FlexPendant.6
After calibration is done use the FlexPendant
to jog each axis to zero degree.
7
See section
• Synchronization marks and
synchronization position for
axes on page 228
The synchronisation marks on axis 3 shall now
be matched.
8
Choose Update Revolution counters from the
Calib menu.
9
Choose Axis 3 on the FlexPendant and update
the revoultion counters.
10
Calibration of axis 4 separately
Use this procedure when calibrating axis 4 separately.
InformationAction
DANGER
Turn off all electric power, hydraulic and pneu-
matic pressure supplies to the robot!
1
See section
• Manually releasing the brakes
on page 66
Release the brakes.2
See the figure 4 in:
• Location of calibration pins on
page 242
Rotate axis 4 manually until the two calibration
pins are in contact with each other.
3
Choose fine calibration from Calib menu.4
Choose Calibrate on the the FlexPendant.5
After calibration is done use the FlexPendant
to jog each axis to zero degree
6
See section
• Synchronization marks and
synchronization position for
axes on page 228
The synchronisation marks on axis 4 shall now
be matched.
7
Choose Update Revolution counters from the
Calib menu.
8
Choose Axis 4 on the FlexPendant and update
the revoultion counters.
9
