Inspection, oil level axis-6 gearbox
Use this procedure to inspect the oil level in the axis-6 gearbox.
NoteAction
WARNING
Handling gearbox oil involves several safety risks.
Before proceeding, please read the safety informa-
tion in the section Safety risks during work with
gearbox lubricants (oil or grease) on page 36.
1
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
2
Shown in figure Location of gear-
box on page 107.
Open oil plug, filling.3
Required oil level: 23 mm ± 2 mm below the motor
mounting surface.
4
Art. no. is specified in Required
equipment on page 107.
Add oil if required.5
Further information about how to
fill the oil may be found in the
section Changing oil, gearbox axis
6 on page 130.
Tightening torque: 25 Nm.Refit oil plug, filling.6
108 Product manual - IRB 460
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
3 Maintenance
3.3.3 Inspecting, oil level gearbox axis 6
Continued
