3.3.2 Inspecting, oil level gearbox axes 2 - 3
Location of gearbox, axes 2-3
The gearboxes axes 2-3 are located in the lower arm rotational center, underneath
the motor attachment.
xx1000001295
Gearbox, axis 2A
Oil plug, fillingB
