3.3.4 Inspecting, cable harness
Location of cable harness, axes 1-6
The axes-1-6 cable harness is shown below.
xx1000001373
Cable harness robot, axes 1-6A
Connectors at baseB
Motor cablesC
Cable guide, axis 2D
Metal clampsE
Required equipment
Visual inspection, no tools are needed.
Continues on next page
