4.3 Complete robot
4.3.1 Replacing cable harness, lower end (axes 1-3)
Overview
The cable harness 1-6 is undivided.
How to replace the cable harness is described in two steps - lower end (axes 1-3)
and upper end (axis 6). This procedure describes how to replace the lower end of
the cable harness. How to replace the upper end can be found in section Replacing
the cable harness, upper end (incl. axis 6) on page 157.
