Combined warning label "Brake release", "Brake release buttons" and "Moving
robot", 3HAC054583-001
D
Instruction label for lifting of robot, 3HAC039135-001E
Warning label "Tip risk when loosening bolts", 3HAC9191-1F
Information label at base, specifying which oil is filled in gearboxes, 3HAC032906-
001
G
ABB Logotype, 3HAC17765-2 (2 pcs)H
UL label, 3HAC2763-1J
Information label near each gearbox, specifying which oil is used in gearboxes,
3HAC032726-001 (4 pcs)
K
Label serial numberL
Label calibrationM
Label, batteryN
Label, stock robotsP
Required tools and equipment
Visual inspection, no tools are required.
Inspecting, labels
NoteAction
DANGER
Turn off all:
• electric power supply
• hydraulic pressure supply
• air pressure supply
to the robot, before entering the robot working area.
1
Inspect the labels, located as shown in the figures.2
Article numbers for the labels and
plate set is specified in Spare
parts on page 389.
Replace any missing or damaged labels.3
112 Product manual - IRB 460
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
3 Maintenance
3.3.5 Inspecting the information labels
Continued
