NoteArt. no.Equipment
Not included in gearbox.3HAA1001-172Washers
Replace only if damaged!
3HAB3772-58O-ring
Must be replaced when reas-
sembling gearbox.
3HAB3772-57164.7x3.53
Must be replaced when reas-
sembling gearbox.
3HAB3772-64150.0x2.0
Must be replaced when reas-
sembling gearbox.
3HAB3772-6113.1x1.6
For lubricating o-ring3HAB3537-1Grease
Always use guide pins in
pairs!
-Guide pins
The content is defined in the
section Standard tools on
page 383.
Standard toolkit
These procedures include
references to the tools re-
quired.
Other tools and propcedures
may be rquired. See refer-
ences to these procedures in
the step-by-step instructions
below.
Deciding calibration routine
Decide which calibration routine to be used, based on the information in the table.
Depending on which routine is chosen, action might be required prior to beginning
the repair work of the robot, see the table.
NoteAction
Decide which calibration routine to use for
calibrating the robot.
• Reference calibration. External cable
packages (DressPack) and tools can
stay fitted on the robot.
• Fine calibration. All external cable
packages (DressPack) and tools
must be removed from the robot.
1
Follow the instructions given in the refer-
ence calibration routine on the FlexPendant
to create reference values.
If the robot is to be calibrated with refer-
ence calibration:
Find previous reference values for the axis
or create new reference values. These val-
ues are to be used after the repair proced-
ure is completed, for calibration of the ro-
bot.
Creating new values requires possibility to
move the robot.
Read more about reference calibration for
Axis Calibration in Reference calibration
routine on page 358.If no previous reference values exist, and
no new reference values can be created,
then reference calibration is not possible.
Read more about reference calibration for
Pendulum Calibration in Operating manu-
al - Calibration Pendulum.
If the robot is to be calibrated with fine
calibration:
Remove all external cable packages
(DressPack) and tools from the robot.
Continues on next page
Product manual - IRB 460 339
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
