Hole configuration, base
This illustration shows the hole configuration used when securing the robot.
R400
4 x 15°
4 x 37.5°
xx0600002932
Continues on next page
Product manual - IRB 460 73
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
2 Installation and commissioning
2.3.6 Orienting and securing the robot
Continued
