NoteArticle numberSpare part
The maintenance set contains:
• radial sealing with dust lip,
2 pcs
• groove ball bearing com-
plete, 2 pcs
• retaining ring, bore, 2 pcs
• VK-cover, 2 pcs
(3HAA2166-13)
3HAC087164-001Maintenance set, cradle
Required tools and equipment
NoteArticle numberEquipment
Used to secure lower arm.-Lock screw, M16x120
Used to unload or restore a balan-
cing device.
User instructions are enclosed
with the tool.
3HAC074411-001Hydraulic press equipment, balan-
cing device
Used for removing and fitting
shaft and bearings.
User instructions are enclosed
with the tool.
3HAC028920-001Dismantle and mounting tool
To be used with the press and
puller tools.
See technical specifications in the
user instructions for the press
equipment.
3HAC13086-1Hydraulic pump 80 MPa
To be used with the press and
puller tools.
See technical specifications in the
user instructions for the press
equipment.
3HAC11731-1Hydraulic cylinder
SA-10-8-NA1-Lifting shackle
Lifting instruction 3HAC15880-2
enclosed.
3HAC15556-1Lifting accessory (chain)
Content is defined in section
Standard toolkit on page 628.
-Standard toolkit
Required service parts
NoteArticle numberEquipment
Located at the cradle of the balancing
device. 2 pcs required.
Replace if damaged.
3HAA2166-13VK cover, 100x10
Loctite 2400 (or equivalent Loctite 243)-Locking liquid
Shell Gadus S23HAC042536-001Grease
Continues on next page
220 Product manual - IRB 6710
3HAC085695-001 Revision: A
© Copyright 2023 ABB. All rights reserved.
5 Repair
5.3.3 Replacing the rear bearings on the balancing device
Continued
