Required service parts
NoteArticle numberConsumable
Replace if damaged.
On axis-1 motor
3HAC072864-003
(Graphite White)
3HAC072864-005
(ABB Orange)
3HAC074336-004
(Graphite White,
threaded connection)
3HAC074336-005
(ABB Orange,
threaded connection)
Connection box cover FS180 with
gasket
Loctite 7200-Cleaning agent
Loctite 7063-Cleaning agent
Loctite 5800-Flange sealant
Used on oil plug. Always replace
when refitting oil plug.
3HAC061327-059O-ring, G 1/2"
Required tools and equipment
NoteArticle numberEquipment
300 mm, bits 1/2"3HAC12342-1Bits extender
Always use guide pins in pairs.3HAC15521-2Guide pin, M10x150
Used to push out the motor, if
necessary.
Always use removal tools in
pairs.
3HAC14631-1Removal tool motor M12
User instructions are enclosed
with the tool.
3HAC081310-001Brake release tool
Used to rotate the motor pinion.
Add screw M4.
3HAB7887-1Rotation tool M4
Delivered as a set of calibration
tools.
Required if Axis Calibration is the
valid calibration method for the
robot.
3HAC074564-001
(axes 1, 2, 3 and 4)
3HAC074119-001
(axes 5 and 6)
Calibration toolbox, Axis Calibra-
tion
Content is defined in section
Standard toolkit on page 628.
-Standard toolkit
Continues on next page
Product manual - IRB 6710 349
3HAC085695-001 Revision: A
© Copyright 2023 ABB. All rights reserved.
5 Repair
5.7.1 Replacing the axis-1 motor
Continued
