The contactors are identified as follows:
CN1 = Battery Disconnect (LVBD1)
CN2 = Load 1 Disconnect (LVLD1)
CN3 = Load 2 Disconnect (LVLD2)
CN4 = Load 3 Disconnect (LVLD3)
CNT- Disconnect Contactor Control
Related Commands
Obj,attr Description Sta Cha Ope Type
cnx
11
,ide √ number
cnx11,des Description √ √ number
cnx11,stt Status √ √ FAILED
cnx11,ena √ √ 0=disable,1=enable
cnx11,dth √ √ number
cnx11,dvx √ √ number
cnx11,din √ √ number
cnx11,dix √ √ number
cnx11,ddy √ √
cnx11,ddy √ √ number
cnx11,dam √ √
0=“NONE”
1=“VOLTAGE”
cnx11,dtm √ √ number
disconnect
cnx11,rth √ √ number
cnx11,rdy √ √ number
cnx11,ram √ √
0=“NONE”
1=“VOLTAGE”
2=“VOLTAGE+TIME”
4,rtm √ number reconnect
Related Commands
Obj,attr Description Sta Cha Ope Type
dcmxx
12
,ide √ number
DCM01-
DCM08
dcmxx12,des Description √ √ number
dcmxx12,sn √
dcmxx12,brc √
dcmxx12,stt State √
NONE MISSING
PRESENT
dcmxx12,typ √ √
NONE
LOAD
dcmxx12,val Reading √ number
dcmxx12,sha √ √ number 0-9999 Amps
