Rectifier or Converter Start/Stop Maintenance Operations
The maintenance page in the Pulsar Edge provides a remote user the ability to place a rectifier into
Standby if the “Remote Rectifier In Standby”. A user has the ability to turn-off (Stop) or turn-on (Start)
a specific rectifier. These are based upon the position of the buttons. G11 below has been placed into
Standby and can be turned back on or started by initiating the Start Rectifier for G11. Rectifiers G12
and G13 are On and producing power. These rectifiers can be manually placed into Standby (Off) by
performing the Stop operation.
T1.317 Terminal
The maintenance page provides the user the ability to open a T1.317 command line session over the
network. Clicking the button located at bottom of the page opens up a command-line session that
allows a user to enter and execute specific T1.317 commands.
Enter the specific T1.317 command at the allocated space and press the execute button. The controller
will send its response in the area shown. Clicking on Bye/Close will close out the window and return the
maintenance window.
