ABB RET670 Commissioning Manual

Headline Explanation
Frequency diff: IED vs Sampled value <Access Point><Hardware Module
Identifier><svID>
Where the Hardware Module Identifier is the same as
given in PCM600, e.g.
AP1: MU1_9201 svID: <ABB_MU0101>
Wrong cycle time for PMU report
Wrong cycle time on SMAI or 3PHSUM block
connected to Phasor Report block. The SMAI or
3PHSUM block should have the same cycle time as
that of Phasor Report.
PMU not connected to 3ph output
The PMU phasor report input(s) must be connected
to the 3ph output of SMAI or 3PHSU.
Invalid value set for PMU Parameters There are two explanations possible:
Check if the following parameters are set correctly on
PMUREPORT:
ReportRate or SvcClass or
parameter PRIMVAL:1.FrequencySel is not set as
50Hz / 60Hz.
Check if the following parameters are set correctly on
PMUREPORT:
ReportRate or SvcClass or
RptTimetag or parameter PRIMVAL:1.FrequencySel
is not set as 50Hz / 60Hz.
Invalid phase angle reference
The selected PhaseAngleRef corresponds to an
analog channel that is not configured. Please
configure a valid reference channel.
GOOSE is configured on a disabled port
At least one of the access points configured for
GOOSE is disabled. The port can be disabled either
through changing the access point operation to off or
by unchecking the GOOSE protocol from the access
point in the Ethernet configuration in PCM600 or
LHMI.
Please enable GOOSE on access points:
AP_FRONT, AP_1
LDCM not running the application image <slot number> is running the factory image instead of
the application image. The factory image is older and
does not contain the latest updates and fixes.
Please reboot the IED. If the problem persists update
the LDCM firmware or replace the board.
LDCM version is not accepted
<device name> firmware version <version string> is
not accepted. The minimum accepted version is
<version string>.
Please update the LDCM firmware or replace the
board.
OEM not running the application image
OEM in slot <slot number> is running the factory
image instead of the application image. The factory
image is older and does not contain the latest
updates and fixes.
Please reboot the IED. If the problem persists,
update the OEM firmware or replace the board.
Section 15 1MRK 504 165-UUS -
Troubleshooting
308 Transformer protection RET670 2.2 ANSI
Commissioning manual
