ABB RET670 Commissioning Manual

Section 7 Establishing connection and verifying the
LON communication
7.1 Communication via the rear ports
7.1.1 LON communication
LON communication is normally used in substation automation systems. Optical fiber is
used within the substation as the physical communication link.
The test can only be carried out when the whole communication system is installed. Thus,
the test is a system test and is not dealt with here.
Control Center
IED IEDIED
Gateway
Star coupler
RER 111
Station HSI
MicroSCADA
IEC05000663-1-en.vsd
IEC05000663 V2 EN
Figure 8: Example of LON communication structure for a substation automation
system
An optical network can be used within the substation automation system. This enables
communication with the IEDs through the LON bus from the operator’s workplace, from
1MRK 504 165-UUS - Section 7
Establishing connection and verifying the LON communication
Transformer protection RET670 2.2 ANSI 65
Commissioning manual

ABB RET670 Specifications

General

Rated Frequency	50/60 Hz
Inputs	Analog and binary inputs
Application	Protection of power systems
Communication Protocols	IEC 61850, DNP3, Modbus
Operating Temperature Range	-25°C to +55°C
Mounting	Rack mounted
Number of Binary Inputs	Up to 48
Number of Binary Outputs	32
Protection Functions	Overcurrent Protection
Outputs	Binary outputs
Enclosure	IP 54
Type	Line Differential Protection
Number of Analog Inputs	24
