Section 8 Establishing connection and verifying the
IEC 61850 communication
8.1 Overview
The rear optical Ethernet ports are used for:
process bus (IEC/UCA 61850-9-2LE) communication
IEEE C37.118/1344 communication
substation bus (IEC 61850-8-1) communication
8.2 Setting the station communication
To enable IEC 61850 communication the corresponding ports must be activated. The rear
access points can be used for IEC 61850-8-1 and IEC/UCA 61850-9-2LE
communication. IEC 61850-8-1 redundant communication requires the use of two
Ethernet ports, when it is activated for Ethernet port the next immediate port is selected as
the second Ethernet port and will become hidden.
To enable IEC 61850 station communication:
In this example access points 1, 2 and 3 are used.
1. Activate IEC 61850-8-1 (substation bus) communication.
Navigate to: Main menu/Configuration/Communication/Station
communication/IEC61850–8–1/IEC61850–8–1:1
2. Enable operation for Access Point 1 and 3 in the Ethernet configuration tool (ECT)
in PCM600.
3. Enable redundant communication for Acess point 1 using ECT.
1MRK 504 165-UUS - Section 8
Establishing connection and verifying the IEC 61850 communication
Transformer protection RET670 2.2 ANSI 71
Commissioning manual
