ScreenMaster RVG200
Paperless recorder 7 Configuration
OI/RVG200-EN 109
Tag Enter the F0 tag to be displayed in the Indicator view and the Totalizer log
(6 characters maximum).
Refer to Appendix F, page 180 for further information regarding character
use in tags.
Note. The default tag text includes 'F0' to distinguish an F0 value in the
Totalizer log but this can be changed.
Stop/Go/Reset Select the action following a power failure and a digital signal to stop and
start the F0 value calculation:
Stop/Go recovery Last
Stop
Go
–
–
–
on power recovery, the F0 value calculation continues in the
same state as before the failure, either stopped or running.
F0 value calculation stops.
F0 value calculation continues from the last recorded value.
Stop/Go source Select a signal source to stop and start the F0 value calculation; Refer to
Appendix A, page 146 for a description of the available sources.
Note. This signal is edge-triggered. A rising edge (inactive to active) starts
the calculation. A falling edge (active to inactive) stops the calculation.
Reset source Select a signal source (see Appendix A, page 146) – an edge-triggered
signal to reset the calculation on a rising edge.
Target Temp/Z Value Default values for the target temperature and Z factor are pre-configured
but can be changed.
Target Temperature Enter the required target temperature.
Z Value Enter the required Z value.
Start
Stop
