ScreenMaster RVG200
Paperless recorder Appendix B – MODBUS TCP / MODBUS 485
OI/RVG200-EN 161
4A 125 and 126 10A 173 and 174 16A 221 and 222 22A 269 and 270
4B 127 and 128 10B 175 and 176 16B 223 and 224 22B 271 and 272
4C 129 and 130 10C 177 and 178 16C 225 and 226 22C 273 and 274
4D 131 and 132 10D 179 and 180 16D 227 and 228 22D 275 and 276
5A 133 and 134 11A 181 and 182 17A 229 and 230 23A 277 and 278
5B 135 and 136 11B 183 and 184 17B 231 and 232 23B 279 and 280
5C 137 and 138 11C 185 and 186 17C 233 and 234 23C 281 and 282
5D 139 and 140 11D 187 and 188 17D 235 and 236 23D 283 and 284
6A 141 and 142 12A 189 and 190 18A 237 and 238 24A 285 and 286
6B 143 and 144 12B 191 and 192 18B 239 and 240 24B 287 and 288
6C 145 and 146 12C 193 and 194 18C 241 and 242 24C 289 and 290
6D 147 and 148 12D 195 and 196 18D 243 and 244 24D 291 and 292
Totalizer Maximum flowrate
(IEEE)
Minimum flowrate
(IEEE)
Average flowrate
(IEEE)
Batch total
(double precision)
Batch total
(IEEE)
1A 501 and 502 601 and 602 701 and 702 801 to 804 1001 and 1002
1B 503 and 504 603 and 604 703 and 704 805 to 808 1003 and 1004
2A 505 and 506 605 and 606 705 and 706 809 to 812 1005 and 1006
2B 507 and 508 607 and 608 707 and 708 813 to 816 1007 and 1008
3A 509 and 510 609 and 610 709 and 710 817 to 820 1009 and 1010
3B 511 and 512 611 and 612 711 and 712 821 to 824 1011 and 1012
4A 513 and 514 613 and 614 713 and 714 825 to 828 1013 and 1014
4B 515 and 516 615 and 616 715 and 716 829 to 832 1015 and 1016
5A 517 and 518 617 and 618 717 and 718 833 to 836 1017 and 1018
5B 519 and 520 619 and 620 719 and 720 837 to 840 1019 and 1020
6A 521 and 522 621 and 622 721 and 722 841 to 844 1021 and 1022
6B 523 and 524 623 and 624 723 and 724 845 to 848 1023 and 1024
7A 525 and 526 625 and 626 725 and 726 849 to 852 1025 and 1026
7B 527 and 528 627 and 628 727 and 728 853 to 856 1027 and 1028
8A 529 and 530 629 and 630 729 and 730 857 to 860 1029 and 1030
8B 531 and 532 631 and 632 731 and 732 861 to 864 1031 and 1032
9A 533 and 534 633 and 634 733 and 734 865 to 868 1033 and 1034
9B 535 and 536 635 and 636 735 and 736 869 to 872 1035 and 1036
10A 537 and 538 637 and 638 737 and 738 873 to 876 1037 and 1038
10B 539 and 540 639 and 640 739 and 740 877 to 880 1039 and 1040
11A 541 and 542 641 and 642 741 and 742 881 to 884 1041 and 1042
11B 543 and 544 643 and 644 743 and 744 885 to 888 1043 and 1044
12A 545 and 546 645 and 646 745 and 746 889 to 892 1045 and 1046
12B 547 and 548 647 and 648 747 and 748 893 to 896 1047 and 1048
13A 549 and 550 649 and 650 749 and 750 897 to 900 1049 and 1050
13B 551 and 552 651 and 652 751 and 752 901 to 904 1051 and 1052
14A 553 and 554 653 and 654 753 and 754 905 to 908 1053 and 1054
Table B.14 Totalizer totals (current batch)
Read / Write, IEEE floating point 32 bit number
Alarm MODBUS
registers
Alarm MODBUS
registers
Alarm MODBUS
registers
Alarm MODBUS
registers
Table B.13 Alarm trip values (Continued)
