ScreenMaster RVG200
Paperless recorder Appendix B – MODBUS TCP / MODBUS 485
162 OI/RVG200-EN
14B 555 and 556 655 and 656 755 and 756 909 to 912 1055 and 1056
15A 557 and 558 657 and 658 757 and 758 913 to 916 1057 and 1058
15B 559 and 560 659 and 660 759 and 760 917 to 920 1059 and 1060
16A 561 and 562 661 and 662 761 and 762 921 to 924 1061 and 1062
16B 563 and 564 663 and 664 763 and 764 925 to 928 1063 and 1064
17A 565 and 566 665 and 666 765 and 766 929 to 932 1065 and 1066
17B 567 and 568 667 and 668 767 and 768 933 to 936 1067 and 1068
18A 569 and 570 669 and 670 769 and 770 937 to 940 1069 and 1070
18B 571 and 572 671 and 672 771 and 772 941 to 944 1071 and 1072
19A 573 and 574 673 and 674 773 and 774 945 to 948 1073 and 1074
19B 575 and 576 675 and 676 775 and 776 949 to 952 1075 and 1076
20A 577 and 578 677 and 678 777 and 778 953 to 956 1077 and 1078
20B 579 and 580 679 and 680 779 and 780 957 to 960 1079 and 1080
21A 581 and 582 681 and 682 781 and 782 961 to 964 1081 and 1082
21B 583 and 584 683 and 684 783 and 784 965 to 968 1083 and 1084
22A 585 and 586 685 and 686 785 and 786 969 to 972 1085 and 1086
22B 587 and 588 687 and 688 787 and 788 973 to 976 1087 and 1088
23A 589 and 590 689 and 690 789 and 790 977 to 980 1089 and 1090
23B 591 and 592 691 and 692 791 and 792 981 to 984 1091 and 1092
24A 593 and 594 693 and 694 793 and 794 985 to 988 1093 and 1094
24B 595 and 596 695 and 696 795 and 796 989 to 992 1095 and 1096
Totalizer Maximum flowrate
(IEEE)
Minimum flowrate
(IEEE)
Average flowrate
(IEEE)
Batch total
(double precision)
Batch total
(IEEE)
1A 1101 and 1102 1201 and 1202 1301 and 1302 1401 to 1404 1601 and 1602
1B 1103 and 1104 1203 and 1204 1303 and 1304 1405 to 1408 1603 and 1604
2A 1105 and 1106 1205 and 1206 1305 and 1306 1409 to 1412 1605 and 1606
2B 1107 and 1108 1207 and 1208 1307 and 1308 1413 to 1416 1607 and 1608
3A 1109 and 1110 1209 and 1210 1309 and 1310 1417 to 1420 1609 and 1610
3B 1111 and 1112 1211 and 1212 1311 and 1312 1421 to 1424 1611 and 1612
4A 1113 and 1114 1213 and 1214 1313 and 1314 1425 to 1428 1613 and 1614
4B 1115 and 1116 1215 and 1216 1315 and 1316 1429 to 1432 1615 and 1616
5A 1117 and 1118 1217 and 1218 1317 and 1318 1433 to 1436 1617 and 1618
5B 1119 and 1120 1219 and 1220 1319 and 1320 1437 to 1440 1619 and 1620
6A 1121 and 1122 1221 and 1222 1321 and 1322 1441 to 1444 1621 and 1622
6B 1123 and 1124 1223 and 1224 1323 and 1324 1445 to 1448 1623 and 1624
7A 1125 and 1126 1225 and 1226 1325 and 1326 1449 to 1452 1625 and 1626
7B 1127 and 1128 1227 and 1228 1327 and 1328 1453 to 1456 1627 and 1628
8A 1129 and 1130 1229 and 1230 1329 and 1330 1457 to 1460 1629 and 1630
8B 1131 and 1132 1231 and 1232 1331 and 1332 1461 to 1464 1631 and 1632
9A 1133 and 1134 1233 and 1234 1333 and 1334 1465 to 1468 1633 and 1634
9B 1135 and 1136 1235 and 1236 1335 and 1336 1469 to 1472 1635 and 1636
10A 1137 and 1138 1237 and 1238 1337 and 1338 1473 to 1476 1637 and 1638
10B 1139 and 1140 1239 and 1240 1339 and 1340 1477 to 1480 1639 and 1640
11A 1141 and 1142 1241 and 1242 1341 and 1342 1481 to 1484 1641 and 1642
11B 1143 and 1144 1243 and 1244 1343 and 1344 1485 to 1488 1643 and 1644
Table B.15 Totalizer totals (previous batch)
Totalizer Maximum flowrate
(IEEE)
Minimum flowrate
(IEEE)
Average flowrate
(IEEE)
Batch total
(double precision)
Batch total
(IEEE)
Table B.14 Totalizer totals (current batch) (Continued)
